Prepare Authentication (Signature)

                            //Sign up Wiro dashboard and create project
export YOUR_API_KEY="YOUR_WIRO_API_KEY";
export YOUR_API_SECRET="XXXXXXXXX";

//unix time or any random integer value
export NONCE=$(date +%s);

//hmac-SHA256 (YOUR_API_SECRET+Nonce) with YOUR_API_KEY
export SIGNATURE="$(echo -n "${YOUR_API_SECRET}${NONCE}" | openssl dgst -sha256 -hmac "${YOUR_API_KEY}")";



Create a New Folder - Make HTTP Post Request

Create a New Folder - Response

Upload a File to the Folder - Make HTTP Post Request

Upload a File to the Folder - Response

Run Command - Make HTTP Post Request (JSON)


# ⚠️ IMPORTANT: Remove all commented lines (starting with #) before running
# Bash doesn't support comments in command continuation (lines ending with \)

curl -X POST "https://api.wiro.ai/v1/Run/fluxlisimo/drawio-v2"  \
-H "Content-Type: application/json" \
-H "x-api-key: ${YOUR_API_KEY}" \
-H "x-nonce: ${NONCE}" \
-H "x-signature: ${SIGNATURE}" \
-d '{
  "prompt": "<lora:Drawio-v2:1.0>, fluxlisimo_drawio, A colossal dragon's head rests heavily on the ground, its mouth closed and only one massive amber eye open — glowing faintly, reflecting the silhouette of a hooded human standing beside it. The rest of the dragon’s body remains unseen, its head alone dominating the cracked earth. The hooded figure stands close, arm extended upward, fingers reaching toward the eye, dwarfed by the immense size.In the foreground, the dragon’s eye is captured in a tight cinematic close-up — its intricate textures, luminous reflections, and layered depth emphasized. The amber iris seems ancient, like fossilized flame, revealing flecks of gold and deep red within. The reflection of the small human hand reaching toward it is clearly visible on the surface of the eye.The barren landscape and broken ground add to the weight of the moment, shadows stretching wide under a heavy, silent sky.G0thicL1nes",
  "samples": "1",
  "steps": "35",
  "scale": "3.5",
  "seed": "42748",
  "width": "1024",
  "height": "1024",
  "callbackUrl": "Optional: Webhook URL for task completion notifications"
}';




Run Command - Response


//response body
{
    "errors": [],
    "taskid": "2221",
    "socketaccesstoken": "eDcCm5yyUfIvMFspTwww49OUfgXkQt",
    "result": true
}



Get Task Detail - Make HTTP Post Request with Task Token


curl -X POST "https://api.wiro.ai/v1/Task/Detail"  \
-H "Content-Type: application/json" \
-H "x-api-key: ${YOUR_API_KEY}" \
-H "x-nonce: ${NONCE}" \
-H "x-signature: ${SIGNATURE}" \
-d '{
  "tasktoken": "eDcCm5yyUfIvMFspTwww49OUfgXkQt"
}';




Get Task Detail - Response


//response body
{
  "total": "1",
  "errors": [],
  "tasklist": [
      {
          "id": "534574",
          "uuid": "15bce51f-442f-4f44-a71d-13c6374a62bd",
          "name": "",
          "socketaccesstoken": "eDcCm5yyUfIvMFspTwww49OUfgXkQt",
          "parameters": {
              "inputImage": "https://api.wiro.ai/v1/File/mCmUXgZLG1FNjjjwmbtPFr2LVJA112/inputImage-6060136.png"
          },
          "debugoutput": "",
          "debugerror": "",
          "starttime": "1734513809",
          "endtime": "1734513813",
          "elapsedseconds": "6.0000",
          "status": "task_postprocess_end",
          "cps": "0.000585000000",
          "totalcost": "0.003510000000",
          "guestid": null,
          "projectid": "699",
          "modelid": "598",
          "description": "",
          "basemodelid": "0",
          "runtype": "model",
          "modelfolderid": "",
          "modelfileid": "",
          "callbackurl": "",
          "marketplaceid": null,
          "createtime": "1734513807",
          "canceltime": "0",
          "assigntime": "1734513807",
          "accepttime": "1734513807",
          "preprocessstarttime": "1734513807",
          "preprocessendtime": "1734513807",
          "postprocessstarttime": "1734513813",
          "postprocessendtime": "1734513814",
          "pexit": "0",
          "categories": "["tool","image-to-image","quick-showcase","compare-landscape"]",
          "outputs": [
              {
                  "id": "6bc392c93856dfce3a7d1b4261e15af3",
                  "name": "0.png",
                  "contenttype": "image/png",
                  "parentid": "6c1833f39da71e6175bf292b18779baf",
                  "uuid": "15bce51f-442f-4f44-a71d-13c6374a62bd",
                  "size": "202472",
                  "addedtime": "1734513812",
                  "modifiedtime": "1734513812",
                  "accesskey": "dFKlMApaSgMeHKsJyaDeKrefcHahUK",
                  "foldercount": "0",
                  "filecount": "0",
                  "ispublic": 0,
                  "expiretime": null,
                  "url": "https://cdn1.wiro.ai/6a6af820-c5050aee-40bd7b83-a2e186c6-7f61f7da-3894e49c-fc0eeb66-9b500fe2/0.png"
              }
          ],
          "size": "202472"
      }
  ],
  "result": true
}



Kill Task - Make HTTP Post Request with Task ID


curl -X POST "https://api.wiro.ai/v1/Task/Kill"  \
-H "Content-Type: application/json" \
-H "x-api-key: ${YOUR_API_KEY}" \
-H "x-nonce: ${NONCE}" \
-H "x-signature: ${SIGNATURE}" \
-d '{
  "taskid": "534574"
}';




Kill Task - Response


//response body
{
  "errors": [],
  "tasklist": [
      {
          "id": "534574",
          "uuid": "15bce51f-442f-4f44-a71d-13c6374a62bd",
          "name": "",
          "socketaccesstoken": "ZpYote30on42O4jjHXNiKmrWAZqbRE",
          "parameters": {
              "inputImage": "https://api.wiro.ai/v1/File/mCmUXgZLG1FNjjjwmbtPFr2LVJA112/inputImage-6060136.png"
          },
          "debugoutput": "",
          "debugerror": "",
          "starttime": "1734513809",
          "endtime": "1734513813",
          "elapsedseconds": "6.0000",
          "status": "task_cancel",
          "cps": "0.000585000000",
          "totalcost": "0.003510000000",
          "guestid": null,
          "projectid": "699",
          "modelid": "598",
          "description": "",
          "basemodelid": "0",
          "runtype": "model",
          "modelfolderid": "",
          "modelfileid": "",
          "callbackurl": "",
          "marketplaceid": null,
          "createtime": "1734513807",
          "canceltime": "0",
          "assigntime": "1734513807",
          "accepttime": "1734513807",
          "preprocessstarttime": "1734513807",
          "preprocessendtime": "1734513807",
          "postprocessstarttime": "1734513813",
          "postprocessendtime": "1734513814",
          "pexit": "0",
          "categories": "["tool","image-to-image","quick-showcase","compare-landscape"]",
          "outputs": [
              {
                  "id": "6bc392c93856dfce3a7d1b4261e15af3",
                  "name": "0.png",
                  "contenttype": "image/png",
                  "parentid": "6c1833f39da71e6175bf292b18779baf",
                  "uuid": "15bce51f-442f-4f44-a71d-13c6374a62bd",
                  "size": "202472",
                  "addedtime": "1734513812",
                  "modifiedtime": "1734513812",
                  "accesskey": "dFKlMApaSgMeHKsJyaDeKrefcHahUK",
                  "foldercount": "0",
                  "filecount": "0",
                  "ispublic": 0,
                  "expiretime": null,
                  "url": "https://cdn1.wiro.ai/6a6af820-c5050aee-40bd7b83-a2e186c6-7f61f7da-3894e49c-fc0eeb66-9b500fe2/0.png"
              }
          ],
          "size": "202472"
      }
  ],
  "result": true
}



Cancel Task - Make HTTP Post Request (For tasks on queue)


curl -X POST "https://api.wiro.ai/v1/Task/Cancel"  \
-H "Content-Type: application/json" \
-H "x-api-key: ${YOUR_API_KEY}" \
-H "x-nonce: ${NONCE}" \
-H "x-signature: ${SIGNATURE}" \
-d '{
  "taskid": "634574"
}';




Cancel Task - Response


//response body
{
  "errors": [],
  "tasklist": [
      {
          "id": "634574",
          "uuid": "15bce51f-442f-4f44-a71d-13c6374a62bd",
          "name": "",
          "socketaccesstoken": "ZpYote30on42O4jjHXNiKmrWAZqbRE",
          "parameters": {
              "inputImage": "https://api.wiro.ai/v1/File/mCmUXgZLG1FNjjjwmbtPFr2LVJA112/inputImage-6060136.png"
          },
          "debugoutput": "",
          "debugerror": "",
          "starttime": "1734513809",
          "endtime": "1734513813",
          "elapsedseconds": "6.0000",
          "status": "task_cancel",
          "cps": "0.000585000000",
          "totalcost": "0.003510000000",
          "guestid": null,
          "projectid": "699",
          "modelid": "598",
          "description": "",
          "basemodelid": "0",
          "runtype": "model",
          "modelfolderid": "",
          "modelfileid": "",
          "callbackurl": "",
          "marketplaceid": null,
          "createtime": "1734513807",
          "canceltime": "0",
          "assigntime": "1734513807",
          "accepttime": "1734513807",
          "preprocessstarttime": "1734513807",
          "preprocessendtime": "1734513807",
          "postprocessstarttime": "1734513813",
          "postprocessendtime": "1734513814",
          "pexit": "0",
          "categories": "["tool","image-to-image","quick-showcase","compare-landscape"]",
          "outputs": [
              {
                  "id": "6bc392c93856dfce3a7d1b4261e15af3",
                  "name": "0.png",
                  "contenttype": "image/png",
                  "parentid": "6c1833f39da71e6175bf292b18779baf",
                  "uuid": "15bce51f-442f-4f44-a71d-13c6374a62bd",
                  "size": "202472",
                  "addedtime": "1734513812",
                  "modifiedtime": "1734513812",
                  "accesskey": "dFKlMApaSgMeHKsJyaDeKrefcHahUK",
                  "foldercount": "0",
                  "filecount": "0",
                  "ispublic": 0,
                  "expiretime": null,
                  "url": "https://cdn1.wiro.ai/6a6af820-c5050aee-40bd7b83-a2e186c6-7f61f7da-3894e49c-fc0eeb66-9b500fe2/0.png"
              }
          ],
          "size": "202472"
      }
  ],
  "result": true
}



Get Task Process Information and Results with Socket Connection


<script type="text/javascript">
  window.addEventListener('load',function() {
    //Get socketAccessToken from task run response
    var SocketAccessToken = 'eDcCm5yyUfIvMFspTwww49OUfgXkQt';
    WebSocketConnect(SocketAccessToken);
  });

  //Connect socket with connection id and register task socket token
  async function WebSocketConnect(accessTokenFromAPI) {
    if ("WebSocket" in window) {
        var ws = new WebSocket("wss://socket.wiro.ai/v1");
        ws.onopen = function() {
          //Register task socket token which has been obtained from task run API response
          ws.send('{"type": "task_info", "tasktoken": "' + accessTokenFromAPI + '"}');
        };

        ws.onmessage = function (evt) {
          var msg = evt.data;

          try {
              var debugHtml = document.getElementById('debug');
              debugHtml.innerHTML = debugHtml.innerHTML + "\n" + msg;

              var msgJSON = JSON.parse(msg);
              console.log('msgJSON: ', msgJSON);

              if(msgJSON.type != undefined)
              {
                console.log('msgJSON.target: ',msgJSON.target);
                switch(msgJSON.type) {
                    case 'task_queue':
                      console.log('Your task has been waiting in the queue.');
                    break;
                    case 'task_accept':
                      console.log('Your task has been accepted by the worker.');
                    break;
                    case 'task_preprocess_start':
                      console.log('Your task preprocess has been started.');
                    break;
                    case 'task_preprocess_end':
                      console.log('Your task preprocess has been ended.');
                    break;
                    case 'task_assign':
                      console.log('Your task has been assigned GPU and waiting in the queue.');
                    break;
                    case 'task_start':
                      console.log('Your task has been started.');
                    break;
                    case 'task_output':
                      console.log('Your task has been started and printing output log.');
                      console.log('Log: ', msgJSON.message);
                    break;
                    case 'task_error':
                      console.log('Your task has been started and printing error log.');
                      console.log('Log: ', msgJSON.message);
                    break;
                   case 'task_output_full':
                      console.log('Your task has been completed and printing full output log.');
                    break;
                    case 'task_error_full':
                      console.log('Your task has been completed and printing full error log.');
                    break;
                    case 'task_end':
                      console.log('Your task has been completed.');
                    break;
                    case 'task_postprocess_start':
                      console.log('Your task postprocess has been started.');
                    break;
                    case 'task_postprocess_end':
                      console.log('Your task postprocess has been completed.');
                      console.log('Outputs: ', msgJSON.message);
                      //output files will add ui
                      msgJSON.message.forEach(function(currentValue, index, arr){
                          console.log(currentValue);
                          var filesHtml = document.getElementById('files');
                          filesHtml.innerHTML = filesHtml.innerHTML + '<img src="' + currentValue.url + '" style="height:300px;">'
                      });
                    break;
                }
              }
          } catch (e) {
            console.log('e: ', e);
            console.log('msg: ', msg);
          }
        };

        ws.onclose = function() {
          alert("Connection is closed...");
        };
    } else {
        alert("WebSocket NOT supported by your Browser!");
    }
  }
</script>



Prepare UI Elements Inside Body Tag


  <div id="files"></div>
  <pre id="debug"></pre>
